It guarantees linearity and strength.
Syntesis Luce
Wiring-ready sliding pocket door system for single door with no jambs and architraves
OVERVIEW
FEATURES
Syntesis Luce
Solid wall version
Strengthened brackets system
Reinforced joint
It guarantees linearity and a better linkage of track, frame and verticals.
Profiles integrated structure
Verticals, upright and stop jamb are pre-coated in the solid wall version and to be filled in the stud wall version; this makes them paintable with the same colour of the wall in which the pocket door will be used.
Insertion system for electric box - Syntesis
If required, it is possible to install up to 10 electrical boxes in each panel (5 on one side and 5 on the other).
Alignment bar (patented) - Syntesis, solid wall
It permits to solidly link the pocket with the stop jambs, thus making the assembly easier.
Extractable track system (patented)
It is always possible to substitute worn mechanisms and to add accessories.
14 Horizontal reinforced bars - Syntesis (solid wall)
14 bars made in 7/10 galvanized steel, with a dovetail form which grant an increased strength to lateral pressures (in order to have an un-deformable internal passage).
Protruding close plaster mesh - Syntesis
It joins the counterframe (50x25 mm) with the wall becoming an integral part of it, thus offering an increasing grasp of the laster. The finished wall won’t have faults.
Reinforced bars - Syntesis, solid wall
Increasing the strength of the counterframe up to 40% than before.
Certified runners with ball bearings - Syntesis
They guarantee long lasting, smooth and silent action. Standard door’s weight is 100 Kg.
Syntesis Luce
Stud wall version
Reinforced joint
It guarantees linearity and a better linkage of track, frame and verticals.
Profiles integrated structure
Verticals, upright and stop jamb are pre-coated in the solid wall version and to be filled in the stud wall version; this makes them paintable with the same colour of the wall in which the pocket door will be used.
Strengthened brackets system
It guarantees linearity and strength.
Reinforced bars - Syntesis, stud wall
Increasing the strength of the counterframe up to 40% than before.
Channel for electrical wiring
Galvanised steel channel where to insert electrical wiring, equipped with earth cable.
12 horizontal reinforcing bars
12 for the stud wall version made in 7/10 galvanized steel, with a dovetail form which grant an increased strength to lateral pressures (in order to have an un-deformable internal passage). There are 24 bars with double leaf.
Extractable track system (patented)
It is always possible to substitute worn mechanisms and to add accessories.
Transparent thermoplastic gasket
Completely transparent, it improves the aesthetics of the verticals bars but also the functionality because the door panel leans gently thanks to the resulting air cushion.
Under-door profile
It improves the strenght and the integrity of the pocket door.
Alignment bar (patented) - Syntesis, stud wall
It permits to solidly link the pocket with the stop jambs, thus making the assembly easier.
